Home > Stainless Steel Angles
Harshita Stainless is a leading producer and supplier of Stainless Steel Angles in Delhi, India. Our SS angles are being extensively used for structural and fabrication purposes owing to their high strength, durability, and resistance to corrosion. Produced in grades such as SS 304, 316, and 202, the angles are available in size and thickness ranges to suit industry requirements. Used in construction, motor vehicle frameworks, or machinery, Harshita Stainless offers products of the highest quality with accurate dimensions and a fine surface finish. Harshita stainless steel angles are fit for heavy-duty and harsh climatic conditions, making them ideal for commercial and industrial purpose
Composed mostly of SS 304 and 316, stainless steel angles hold 18–20% chromium and 8–12% nickel, which makes them highly corrosion resistant. SS 316 adds molybdenum for additional pitting resistance. The tensile strength is 520–750 MPa and yield strength is approximately 200–300 MPa. The angles have good welding and machining properties and can endure high mechanical stress. The stainless steel composition ensures rust resistance, oxidation protection, and structural integrity in demanding environments, making them suitable for long-term structural use.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
Stainless steel angles are L-shaped structural components made from stainless steel. They provide strength and support for various applications, including construction, manufacturing, and architectural projects, offering durability and corrosion resistance.
Stainless steel equal angles have two legs of equal length, forming a 90-degree angle. They are used for structural support and reinforcement in construction, offering strength, durability, and corrosion resistance.
Stainless steel unequal angles have legs of different lengths, forming a 90-degree angle. They provide versatile support and reinforcement in construction and industrial applications, offering strength, durability, and corrosion resistance.
Stainless steel L angles are L-shaped structural components used for framing and support. They offer strength, durability, and corrosion resistance, making them suitable for construction, manufacturing, and architectural applications.
SS T-bar angles are stainless steel sections with a T-shaped profile, providing robust support and stability. They are used in structural applications and frameworks, offering high strength, durability, and corrosion resistance.
Stainless steel corner angles are L-shaped sections designed for joining or reinforcing corners in construction and fabrication. They provide strong, durable, and corrosion-resistant support for various structural and architectural applications.
Stainless Steel Angles find application extensively in building construction, metal frames, brackets, industrial platforms, and support frameworks. They give strength and stability to structural use and are preferred in automotive, shipbuilding, railway, and infrastructure projects. Because of corrosion-resistant and chemical exposure-resistant characteristics, they are also suitable for food processing, pharmaceutical facilities, and sea environments. Harshita Stainless offers angles all over Delhi and India, providing guaranteed performance and reliability in varied industrial use.
