Stainless Steel 316L stud bolts are produced in Delhiand India for highly corrosive applications like marine, chemical, and food processing industries. SS 316L is the low-carbon version of 316 with high corrosion resistance and weldability, particularly in chloride-rich environments. They are best suited for applications with high strength, durability, and low possibility of intergranular corrosion after welding. Produced to ASTM A193 specification, 316L stud bolts are offered in numerous thread forms and sizes. Supplied with precision machining, corrosion-resisting finishes, and full traceability, they are for use in high-integrity bolted connections.
SS 316L is composed of 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and ≤0.03% carbon. The lower carbon content improves resistance to sensitization after welding. These bolts provide tensile strength between 485–620 MPa, yield strength between 170–210 MPa, and elongation of 35%. The molybdenum provides improved resistance to pitting as well as crevice corrosion in the chloride-containing environments. SS 316L also serves very well under moderate temperatures and is not magnetic in the annealed state, providing reliable strength and corrosion protection in severe structural applications.
| Grade | Stainless Steel 316L Fasteners. |
| Standard | ASTM A193 / A194, ASME SA193 / SA194, IS, BS, ANSI |
| Size | M02 to M33 |
| Length | 5 METERS |
| Grade | C | Ni | Mn | S | Cr | Si | P | Mo | N | |
| SS 316L | min. | – | 10.0 | – | – | 16.0 | – | – | 2.00 | – |
| max. | 0.08 | 14.0 | 2.00 | 0.03 | 18.0 | 0.75 | 0.045 | 3.00 | 0.10 | |
| Grade | Yield Strength 0.2% Proof (MPa) min | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| SS 316L | 170 | 485 | 40% | 95 | 217 |
Contact us to get a quick quote for your requirement.
These have threads on both ends, designed for secure connections in flanges or equipment. Ideal for high-corrosion environments due to 316L’s excellent resistance.
Fully threaded rods offer versatile fastening solutions in structural and mechanical applications. Known for superior corrosion resistance in marine and chemical environments.
These are high-strength fasteners with threads throughout or at both ends. Perfect for applications requiring durability and resistance to corrosion.
Conforming to DIN 1.4301 standards, these bolts provide precise dimensions and quality assurance. Suitable for a variety of industries requiring corrosion-resistant fasteners.
Manufactured under UNS S31600 designation, these bolts ensure high strength and excellent corrosion resistance. Ideal for chemical, petrochemical, and marine applications.
These bolts feature a flush head for smooth, low-profile applications. Designed for environments demanding both aesthetic appeal and high performance.
We have high-quality assurance of the complete transparency of our Stainless Steel 316L Stud Bolts. All the orders are provided with all the required documents such as commercial invoice, packing list, fumigation certificate, heat treatment chart, and an NABL-approved lab test report. We provide a Material Test Certificate as per EN 10204/3.1b, PMI Test Certificate, 100% radiography test report, and Third-Party Inspection Certificate. Our entire documentation is provided for the highest client satisfaction.
316L stud bolts have large applications in marine equipment, chemical plants, food-grade machinery, pharmaceutical reactors, and heat exchangers. Their corrosion resistance against rust and chemical attack qualifies them for use to fasten flanges, pumps, and valves under corrosive service conditions. SS 316L bolts are also very popular in welded structures, since the low carbon composition negates the requirement for post-weld heat treatment. These fasteners find application in offshore platforms, sewage treatment facilities, and desalination plants. Their mechanical strength, corrosion resistance, and durability provide a tight fit and long service life in challenging conditions.
