Home > Electrodes > AWS Class E316/316L-16 Electrodes
Harshita Stainless, a prominent manufacturer and supplier located in Delhi, India, is well-known for its top-notch welding consumables, particularly the AWS Class E316/316L-16 Electrodes. These electrodes are expertly crafted for welding low-carbon 316 and similar austenitic stainless steels, providing outstanding resistance to corrosion and high-temperature oxidation. With a strong reputation for quality, precision, and reliable performance, Harshita Stainless caters to essential industries like food processing, pharmaceuticals, petrochemicals, and marine sectors. The E316/316L-16 electrodes minimize carbide precipitation and offer remarkable weld metal ductility, making them perfect for applications where corrosion resistance and weld integrity are crucial under demanding conditions.
AWS Class E316/316L-16 Electrodes consist of about 18–20% Chromium, 11–14% Nickel, and 2–3% Molybdenum, along with a low carbon content (≤0.04%) to help prevent intergranular corrosion. These components significantly boost resistance to pitting and crevice corrosion, especially in chloride-rich settings. When using E316/316L-16 electrodes, the weld metal typically reaches a tensile strength of around 580 MPa, a yield strength of 380 MPa, and an elongation of 30%. These electrodes ensure smooth arc stability, minimal spatter, and easy slag removal, and they can be utilized with both AC and DC power sources in any welding position.
| Classification | AWS A5.4, E316/316L-16 |
| Form | Welding Electrode, Welding Rods |
| Type Of Current | AC-DCEP (Direct Current Electrode Positive) |
| Welding Position | F, V, OH, H |
| Size | 2.0 mm, 2.50 mm, 3.15 mm, 4.00 mm, 5.0 mm |
| AC/DC+ | AC or DC (+) |
| JIS Specification | BS 2926 19.9 A R |
| Other Specification | DIN 8556 E19 9 R 23 A |
| AWS E316/316L-16 Coated Electrodes Application & uses |
|
| C | Cr | Ni | Mo | Mn | Si | P | S | Cu |
| 0.05 | 1.60 | 0.40 | 12 | 19 | 2.30 | 0.20 | 5.5 | FN |
Contact us to get a quick quote for your requirement.
Offering excellent corrosion resistance, these electrodes are available in sizes ranging from 3/32″ to 3/16″. They are ideal for welding thin sections of stainless steel, providing smooth arc stability and low spatter.
Designed for superior corrosion resistance, these heavy-coated electrodes come in sizes from 1/8″ to 3/16″. They ensure deep penetration and high deposition rates, making them suitable for thicker materials and high-stress applications.
These electrodes provide exceptional corrosion resistance and are available in sizes ranging from 1/16″ to 5/32″. They offer excellent shielding properties, ensuring minimal contamination and consistent weld quality suitable for various industrial applications.
We ensure full transparency of our AWS Class E316/316L-16 Electrodes with high-quality assurance. All orders come with essential documents, including a commercial invoice, packing list, fumigation certificate, heat treatment chart and an NABL-approved lab test report. We provide a Material Test Certificate per EN 10204/3.1b, PMI Test Certificate, 100% radiography test report, and a Third-Party Inspection Certificate. Our comprehensive documentation is designed to ensure maximum client satisfaction.
AWS Class E316/316L-16 Electrodes are perfect for welding 316 and 316L stainless steels in corrosive and high-temperature settings. They are commonly used in the fabrication and maintenance of chemical processing equipment, food and beverage facilities, pharmaceutical vessels, marine hardware, pipelines, and heat exchangers. Their exceptional resistance to pitting, acids, and chlorides makes them particularly well-suited for coastal and marine environments.
